Pump Strainer for Swimming Pools & Waterparks
MAT POOL TECHNOLOGY manufactures its own pump strainer for swimming pools and waterparks to provide efficient flow rate without cavitation while at the same time it extends the pump’s lifetime. Years of experience has proven the fact that companies in the business are in need of strainers for the protection of pumps, compressors, turbines, meters, automatic valves and other pipeline equipment.
MAT Strainers can be manufactured by Polyethylene, Polypropylene and Stainless Steel as per your request. Most of private swimming pool filtration pumps come with their own basket strainer.
Commercial pool filtration pumps and waterpark impulsion pumps are unique and may have larger than 800 m3/h flow rate. MAT POOL TECHNOLOGY manufacturing rate is from 10 m3 to 1000 m3 as custom made.
Pump Strainers - SPECIFICATIONS
|Flange Size||Height (mm)||Inlet Level (mm)||Outlet Level (mm)||Body Diameter (mm)||Max. Width (mm)||Max Flowrate (m³/h)||Mesh Size (mm)||Vmin-Vmax (m/s)||Dry Weight (kg)||Operational Weight (kg)||Material|
|DN 100||985||450||200||400||620||50||5||0.5 - 2||50||125||PE / Polycarbonate|
|DN 125||985||460||305||400||630||85||5||0.5 - 2||50||125||PE / Polycarbonate|
|DN 150||985||460||275||400||640||115||5||0.5 - 2||52||128||PE / Polycarbonate|
|DN 200||940||505||350||400||650||220||5||0.5 - 2||52||130||PE / Polycarbonate|
|DN 300||1391||775||280||500||760||430||5||0.5 - 2||113||290||PE / Polycarbonate|
|DN 350||1531||960||577||500||780||650||5||0.5 - 2||122||325||PE / Polycarbonate|
